mSATA
4GB ~ 256GB
mSATA 3IE3
特点
- 搭载 SATA 6.0Gb/s 接口
- 支持 iSMART 硬盘健康监控
- 具备智能错误恢复机制
- 提供优异的数据传输速度
- 零机械干扰
- 防振动机械设计
- 符合 JEDEC MO-300 标准尺寸
- 支持 -40°C 至 85°C 的宽温范围
宜鼎 mSATA 3IE3 采用 mSATA 规格设计，尺寸符合 JEDEC 制定的 MO-300 / MO-300B 标准，支持 SATA III 标准（6.0 Gb/s）接口，提供出色性能。在机械干扰方面，可完全取代传统硬盘，使个人电脑在各种应用领域中更小巧、易用。
mSATA 3IE3 能有效缩短操作系统的启动时间，功耗远低于 HDD，并符合 ATA 协议，可作为启动装置或数据存储装置使用，无需额外驱动程序。
Write Protect 防写技术保护数据安全
探索多元应用场景与成功实例
STABILITY-OPTIMIZED HARDWARE SOLUTIONS FOR LIFE-SAVING VENTILATORS
A leading European manufacturer of ICU ventilators and respirator solutions tasked Innodisk with supplying a significant volume of healthcare-optimized memory and storage solutions for their ventilators. Due to the extremely key role of ventilators, the memory and storage solutions needed to meet stringent stability requirements.
规格表
| Model Name | mSATA 3IE3 |
|---|---|
| Flash Type | iSLC (MLC) |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | MO-300 |
| Capacity | 4GB ~ 256GB |
| Sequential R / W (MB/sec, max.) | 440 / 230 |
| P/E Cycle | 20,000 |
| TBW (Max.) | 694 |
| Storage Temperature | -55°C ~ 95°C |
| Max. Power Consumption | 2.5W |
| Max. Channels | 4 |
| External DRAM Buffer | N |
| Feature | H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 29.85 x 50.8 x 3.7 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 5 Years |
产品料号
工作温度 | 标准温度 | 工业级温度 |
4GB | DHMSR-04GD09BC1SC | DHMSR-04GD09BW1SC |
8GB | DHMSR-08GD09BC1&C | DHMSR-08GD09BW1&C |
16GB (4CH) | DHMSR-16GD08BC1QC | DHMSR-16GD08BW1QC |
16GB (2CH) | DHMSR-16GD09BC1DC | DHMSR-16GD09BW1DC |
32GB (4CH) | DHMSR-32GD08BC1QC | DHMSR-32GD08BW1QC |
32GB (2CH) | DHMSR-32GD09BC1DC | DHMSR-32GD09BW1DC |
64GB (4CH) | DHMSR-64GD08BC*QC | DHMSR-64GD08BW*QC |
64GB (2CH) | DHMSR-64GD09BC*DC | DHMSR-64GD09BW*DC |
128GB | DHMSR-A28D08BC*QC | DHMSR-A28D08BW*QC |
256GB | DHMSR-B56D08BCAQC | DHMSR-B56D08BWAQC |
*. PCB version control
&. S : 1 channel / D : 2 channels
