DDR5
Non-ECC 无缓冲内存
DDR5 宽温 SODIMM
特点
- 速度最高达 5600MT/s，配备 48GB 大容量
- 工作温度范围：-40°C ~ 95°C（Tc）
- 原厂（Original）等级 DDR5 芯片，具备 on-die ECC 纠错功能
- DDR5 模组搭载 PMIC 和双子通道架构
- 30μ" 金手指确保强固耐用，附带适应严苛环境的抗硫化保护层
- 符合 RoHS 及 CE/FCC 认证
AI 驱动了数据传输需求的增长，而 DDR5 DRAM 正是满足该需求的理想选择。随着设计与研发技术的进步，DDR5 内存容量提升至 48GB、速度达到 5600MT/s，整体性能远超前几代产品。
PERFECTLY ADAPTS TO CHANGING CONDITIONS
By developing specialized testing methods, Innodisk DDR5 Wide Temp. SODIMM modules are designed to operate within industrial-grade temperature ranges of -40°C to 95°C, making them ideal for extreme environments and demanding applications.
HIGHER DATA RELIABILITY, LOWER POWER CONSUMPTION
The DDR5 Wide Temp. SODIMM modules are equipped with a on-module power management IC (PMIC) to maintain a stable power supply at 1.1V, ensuring consistent and efficient operation. Additionally, the IC features an on-die ECC function, providing an extra layer of protection against data loss, reducing the risk of errors, and enhancing overall reliability.
SAFEGUARDING MODULES WITH ANTI-SULFURATION PROTECTIVE LAYER
Sulfur is pervasive in many industries. When silver alloys in the DRAM chip encounters sulfur gasses a corrosion reaction occurs. This sulfuration causes lower conductivity and can quickly lead to product failure. To avoid this, Innodisk adds a protective layer above the vulnerable parts to safeguard the silver alloys.
PROVEN RELIABILITY THROUGH 3rd PARTY TESTING
Ensuring the durability and reliability of components is essential for meeting the demands of challenging environments. Our solutions undergo rigorous third-party testing, adhering to stringent industry standards. These tests validate the robustness of our products under extreme conditions, ensuring dependable performance across various applications.
| Thermal Shock | -40°C ~ 110°C, 500 Cycles |
| Anti-sulfuration Test | 480 Hours, ASTM B809-95 |
探索多元应用场景与成功实例
协助 AUV 系统进行深海探测
宜鼎提供高标准 DDR5 4800 16GB 宽温 SODIMM 内存模组，支持客户的自主式水下航行器（AUV）系统，助力海底资源勘探。该内存模组可耐受极端温度环境，并配套宜鼎全方位技术支持服务。
规格表
| Model Name | DDR5 Wide Temperature SODIMM |
|---|---|
| DDR Generation | DDR5 Memory |
| DIMM Type | SODIMM |
| Speed | 4800 MT/s, 5600 MT/s |
| Density | 8GB, 16GB, 24GB, 32GB, 48GB |
| Function | Non-ECC Unbuffered Memory |
| Pin Number | 262pin |
| Bus Width | x64 |
| Voltage | 1.1V |
| PCB Height | 1.18 Inches |
| Operating Temperature | -40°C ~ 95°C (Tc) |
| 30μ” Gold Finger | Y |
| Anti-Sulfuration | Y |
产品料号
型号 | IC 配置 | Rank | 温度 | 简介 |
M5S0-8GSYZ5ZQ | 1G x 16 | 1R x 16 | -40°C ~ 95°C (Tc) | DDR5 5600 8GB Wide Temperature SODIMM |
M5S0-8GMYZ5ZQ | 1G x 16 | 1R x 16 | -40°C ~ 95°C (Tc) | DDR5 5600 8GB Wide Temperature SODIMM |
M5S0-AGS2N5ZQ | 2G x 8 | 1R x 8 | -40°C ~ 95°C (Tc) | DDR5 5600 16GB Wide Temperature SODIMM |
M5S0-AGM2N5ZQ | 2G x 8 | 1R x 8 | -40°C ~ 95°C (Tc) | DDR5 5600 16GB Wide Temperature SODIMM |
M5S0-FGMZN5ZQ | 3G x 8 | 1R x 8 | -40°C ~ 95°C (Tc) | DDR5 5600 24GB Wide Temperature SODIMM |
M5S0-BGS2O5ZQ | 2G x 8 | 2R x 8 | -40°C ~ 95°C (Tc) | DDR5 5600 32GB Wide Temperature SODIMM |
M5S0-BGM2O5ZQ | 2G x 8 | 2R x 8 | -40°C ~ 95°C (Tc) | DDR5 5600 32GB Wide Temperature SODIMM |
M5S0-GGMZO5ZQ | 3G x 8 | 2R x 8 | -40°C ~ 95°C (Tc) | DDR5 5600 48GB Wide Temperature SODIMM |
*Please contact Innodisk for products with other speeds.
